Description
Product Color: Λευκό/ White
|Poles (Gacia): 3P+N
|Supply Voltage (V): 230V
|Operating Frequency (Hz): 50/60Hz
|Contact Position Indication (Gacia): Ναι/ Yes
|Surge Protection: Όχι/ No
|Amperage (A): 40A
|Rated Short Circuit Breaking Capacity (Gacia): 10kA
|Breaking Capacity (Gacia): 10kA
|Ingress Protection (IP): IP20
|Length: 77,5mm
|Width: 70mm
|Height: 87mm
|Product Gross Weight (Kg): 0,440kg
|Packing (pcs): 3\30
|Years of Warranty: 2 Χρόνια/ 2 Years
|Certifications: Ναι/ Yes
|Product Standard (Gacia): IEC/EN 60898-1
|CE Mark: Ναι/ Yes
|Operating Temperature °C: -25°C – +50°C
|Product Material: Πολυαμίδιο/ Polyamide
|Service Life (Gacia): Μηχανικός: 10000 Ηλεκτρικός: 4000/ Mechanical: 10000 Electrical: 4000
|Curve (Gacia): C
|Terminal Connection Type (Gacia): Καλώδιο, Γέφυρα Χαλκού Τύπου L & U/ Wire, L & U Type Busbar
|Fault Indication (Gacia): Όχι/ No
|
