Περιγραφή
Construction size | 4p, 2-module |
Rated operation current Ie at AC-1 (A) | 25 |
Voltage type (excitation voltage) | AC |
Rated excitation voltage | 230 V 50/60 Hz |
Number of NO contacts | 4 |
Thermal current Ie (A) | 25 |
Built-in depth | 60 mm |
Rated operating voltage | 400 V |
Number of modular spacings | 2 |
Slider for hand switch | NO |
Max. incandescent and halogen lamps load (W) | 2000 |
Max. load compact fluorescent lamps with internal ballasts (VA) | 600 |
Degree of protection (IP) | IP20 (IP40 installation in instal.box) |
Additional equipment possible | YES |
