Description
Product Series: PLUS
|Nominal Power (W): 20W
|Supply Voltage (V): 220-240V
|Operating Frequency (Hz): 50/60Hz
|Amperage (A): 100mA
|Color Temperature (K): 4000K
|Luminous Flux (lm): 2100lm
|Lumen/ Watt: 105lm/Watt
|Lumen/ Chip: 130lm/Chip
|Total Chips: 25pcs
|Watt/ Chip: 1W/Chip
|Chip Size: 2835
|Chip Brand: Epistar
|Driver Brand: Embedded Driver DOB
|Included Driver: Ενσωματωμένο στην πλακέτα/ Embedded in plate
|Led Type: SMD2835
|Power Factor (PF): >0,90
|Color Rendering Index CRI (Ra): >80
|Life Time (h): 30000h
|Ingress Protection (IP): IP44
|Impact Resistant (IK): IK06
|Beam Angle: 100°
|Starting Time (sec): 0,5 sec
|Energy Class: A+
|Years of Warranty: 2 Χρόνια/ 2 Years
|Switching Cycles (ON/ OFF): 25000
|Operating Temperature °C: -40°C – +50°C
|Installation Height: 2,5 – 4mtr
|Detector Type: PIR
|Detection Distance: 5mtr – 15mtr
|Product Material: Αλουμίνιο & PC/ Aluminium & PC
|Product Colour: Λευκό/ White
|Length: 137mm
|Width: 180mm
|Height: 50mm
|Product Gross Weight (Kg): 0,380kg
|Packing (pcs): 1\20
|Packaging: Color Box
|Certificates: Ναι/ Yes
|CE Mark: Ναι/ Yes
|Class: Class I
|Connection Type: Καλώδιο/ Wire
|Grounding: Ναι/ Yes
|Cable Cross Section: 3x1mm
|Cable Lenght: 300mm
|General Info: Χρόνος Λειτουργίας Αισθητήρα: 10sec – 8min/ Sensor Working Time: 10sec – 8min
|
