Περιγραφή
| Electrical data | |
| Power supply type : | Alternating current |
| Working voltage [V]: | 20 ÷ 250 |
| Protection class : | III |
| Outputs | |
| Function : | NO |
| Max voltage drop [V]: | < 6 |
| Max output current [mA]: | 300 |
| Minimum output current [mA]: | 5 |
| Max peak current [A]: | 1.5 |
| Residual current [mA]: | < 1 |
| Max switching frequency [Hz]: | 12 |
| Detection zone | |
| Switching distance-Sn [mm]: | 8 |
| Real sensing distance-Sr [mm]: | 8 ±10% |
| Operative distance-So [mm]: | 0 ÷ 6.48 |
| Accuracy and Deviations | |
| Correction factor : | Stainless steel: 0.9 – Brass: 0.5 – Aluminium: 0.4 – Copper: 0.4 |
| Hysteresis [%Sr]: | < 10 |
| Switching point drift [%Sr]: | -10 ÷ +10 |
| Repeatability [%Sn]: | < 3 |
| Environmental conditions | |
| Temperature limits [°C]: | -25 ÷ +70 |
| IP rating : | IP65-IP66-IP67 |
| Display and control elements | |
| Display : | Output switching status – 1 x LED: Yellow |
| Mechanical data | |
| Housing : | Threded type |
| Thread designation : | M18x1 |
| Dimensions [mm]: | M18x1 – L=74.5 |
| Materials : | Housing: Nickel-plated brass – Sensing area: POM blue – Lock nuts: Nickel-plated brass |
| Mounting : | Not embeddable |
| Weigth [g]: | 130 |
| Electrical connection | |
| Cable : | 2 m – PVC/PVC – 2 x 0.50 mm² |
| Compliance to Standards / Directives | |
| Directives compliance : | 2014/30/EU -Electromagnetic compatibility directive (EMC) 2014/35/UE -Low voltage directive (LVD) |
| Standards compliance : | EN60947-5-2 – Product standard |
